I2S Audio Shield

by Unexpected Maker
An image of I2S Audio Shield An image of I2S Audio Shield

This shield takes standard I2S digital audio input from your TinyPICO or TinyS2 and decodes it into an analog audio signal as well as amplifying it for use with an external speaker.

The I2S Audio Shield brings the noise with:

  • MAX98357 I2S Decoder and Amp
    • 3W Class D Amplifier
    • I2S sample rates from 8kHz to 96kHz
    • Click + Pop suppression
    • Thermal shutdown protection
  • Micro SD Card slot
  • Magnetic buzzer for onboard audio via a PAM8301 amplifier
  • A switch to swap between on-board sound and external speaker that can be connected via provided header
  • Comes with a separate screw terminal that can be soldered on for external speaker connection

Using the SD Card

If you are wanting to use the SD Card slot in your project, please ensure you set the SPI MI pin as an INPUT_PULL_HIGH or initialising the slot will fail.

For Arduino: pinMode(MI_PIN, INPUT_PULLUP);

Reviews

User photos

This shield takes standard I2S digital audio input from your TinyPICO or TinyS2 and decodes it into an analog audio signal as well as amplifying it for use with an external speaker.

SHIELD-AUDIO-I2S

You must register for an account and be logged in to view pricing or place an order on the Pimoroni Wholesale store.

If you represent a school or university, a business, or reseller of Maker products then you can sign up for a wholesale account.

If you already have an account you can login to your account here.

Alternatively the easiest way to get your hands on the products we offer is to order them directly from our customer facing online store.

SKU
SHIELD-AUDIO-I2S
EAN
0769894020883
Brand
Unexpected Maker
Stock available
0 units
Backorder not allowed on this product
Weight
9g
