Adafruit Si7021 Temperature & Humidity Sensor Breakout Board - STEMMA QT

Name: Adafruit Si7021 Temperature & Humidity Sensor Breakout Board - STEMMA QT
Brand: Adafruit
SKU: ADA3251
Price: 9.60 GBP
Availability: OutOfStock

by Adafruit

The Si7021 Temperature + Humidity Sensor - the best way to prove the weatherman wrong!

This lovely sensor for Silicon labs has ± 3% relative humidity measurements with a range of 0–80% RH, and ±0.4 °C temperature accuracy at a range of -10 to +85 °C. Great for all of your environmental sensing projects. It uses I2C for data transfer so it works with a wide range of microcontrollers.

To get you going fast, Adafruit spun up a custom made PCB in the STEMMA QT form factor, making them easy to interface with. The STEMMA QT connectors on either side are compatible with the SparkFun Qwiic I2C connectors. This allows you to make solderless connections between your development board and the LIS331s or to chain them with a wide range of other sensors and accessories using a compatible cable. Adafruit have also broken out all the pins to standard headers and added a voltage regulator and level shifting so allow you to use it with either 3.3V or 5V systems such as the Raspberry Pi + Feather series or Arduino Uno respectively.

There's a PTFE filter to keep the sensor clean, that's the white flat thing on top. Also comes with some pin header. Some light soldering is required to attach the header for use in a breadboard but it's easy to do.

Check out this awesome tutorial for how to use it with Arduino or CircuitPython

TECHNICAL DETAILS

Datasheets, schematics, EagleCAD files, Fritzing object and more in the tutorial!

Revision History:

As of August 25, 2020 Adafruit have updated this sensor to be STEMMA QT compatible - that means there's now an easy way to plug-and-play this sensor without any soldering! The physical shape has changed a little, but the pinout is identical.

Product Dimensions: 17.8mm x 15.3mm x 3.0mm / 0.7" x 0.6" x 0.1"

Product Weight: 1.0g / 0.0oz
